A.2.1. Text
Text can added to the template using the following format:
%6% From: %6% 0 0 33 40 20 Arial 9 0 0 2 LEFT BOTTOM
%6%
From: %6%
0
0
33
40
20
Arial
9
0
0
2
LEFT
BOTTOM

(optional) Displaying conditions

The Dynamic/fixed text to be rendered

Text color (0=Black; 1=White)

Specify the rectangle within the text is rendered

Specifies the type, style and size of the used font

Number of lines the text may be wrapped if needed

Horizontal alignment (LEFT, CENTER or RIGHT)

Vertical alignment (TOP, CENTER, BOTTOM)
