7.4. Deleting existing links
Press „2‟ (Unlink ESLs) to delete existing links from the link database. Deleting an existing
link can be done by either entering the product ID or by scanning the product barcode or
the MAC address of the ESL.
7.5. Verifying existing links
It‟s possible to check whether a product has been correctly linked by pressing „3‟ (Product
Info). When entering the product ID or by scanning the product barcode or the MAC
address of the ESL, then it will show the product information and the linked ESL.
7.6. Sending the modified link-database to the PC
After all links have been created using the barcode terminal, this information needs to be
send back to the PC, so they can be processed by the server application. This can be done
by placing the terminal back into its cradle. The terminal should now automatically send the
link database (linked.csv) back to the PC.
After the barcode terminal has sent back the link database, the ESL server application will
call the middleware application to parse the combined database and link database into ESL
image files (bitmaps) and configuration (XML) files and update the ESLs if necessary.
7.7. Settings menu
The settings menu of the terminal can be accessed by pressing „4‟ („Settings). This menu
contains 2 options:
1.
Delete data Deletes all files from the terminal, so also all links that have
not yet been sent back to the PC.
2. Barcodes This menu can enable/disable different barcode
symbologies, so almost all barcodes can be scanned.
7.8. Version
Shows the version of the terminal application, which can be useful for support purposes.
