1. Features and Specifications
1.1. Abstract
This manual provides a preliminary description on how to set-up a customized Electronic
Shelf Labels (ESL) demonstration and how to set-up a pilot project with e-Paper ESLs from
Opticon Sensors Europe BV.
1.2. Contents
The ESL demo kit consists of the following components:
Ethernet ESL base station (EBS-10)
6
2” e-paper ESLs (EE200) including 6x2 CR2450 batteries
UTP cable
6.0V 2A Power supply (European)
PC Installation Software + examples
Opticon Demo Kit User Manual
The demo kit does NOT include a barcode terminal with communication cradle, which can
be used to link ESLs to products using barcodes. Any of the following Opticon Barcode
Terminals can be used for this purpose:
OPH1004 (+ CRD1001 cradle)
H13 (+ CRD13 cradle)
OPL9728 (+ CRD9723RU cradle)
1.3. Physical Features
1.3.1.
Dimensions
2” e-paper ESL (EE200):
W 70.0 x D 32.0 x H 15.0 mm
Base station (EBS-10):
W 129.0 x D 102.0 x H 28.0 mm (excl. antenna)
1.3.2.
Weight
2” e-paper ESL (EE200):
25 g (incl. 2 batteries)
Base station (EBS-10):
125 g (excl. power supply)
