MTS TW Elite User Manual
Page 97
Note:
When you create tests while the TWE application is connected to a controller, it is referred to as
“online” test design. You can also perform “offline” test design (see
(p. 102).)
Resources Tab
Description of Resources Tab
Description
Item
Number
When TWE is connected to a controller, the window title shows the
controller and station configuration associated with the current test. In
Controller and
station
identification
1
this example, the controller name is “MTS FlexTest 40”, and the station
configuration name is “2 chan.cfg”.
The resources in the Name column are test resources. Test resources
are required by the test and must map to equivalent resources in the
Controller Resources column when connected to a controller
Test resources
2
The resources in this column are controller resources. Controller
resources represent resources in the physical station. Resource mapping
Controller
resources
3
is saved with tests. When connected to a station, controller resources
reflect the resources in the Station Configuration file. When not connected
to a station, controller resources reflect the resources the TWE expects
to find when connected to a station.
For More Information
(p. 102)
MTS TestSuite | 97
Working with MTS FlexTest Resources
