Electrical installation
Control terminals
With function "Safe torque off" deactivated
5
l
96 EDKVF9338 DE/EN/FR 4.0
Supply via external voltage source
GND2 +24V +5 V
E5 A2 A3 A4 ST1ST2 59 39
3k 47k
50mA 50mA 50mA 50mA
X5 28 E1 E2 E3 E4
3k 3k 3k 3k 3k
DC 24 V
(+18 V … +30 V)
X11 K31K32 33 34
S1
+
K
SR
+ –
A1
X3
GND1 GND1
X6 1 2 3 4 7 7 62 63
242R
1
2
3
4
5
6
100k 100k 100k 100k
3.3nF
AIN1 AIN2
AOUTx
AOUT2
AOUT1
1 3 2 4 7
10k 10k
9300vec138
Fig. 5−13 Wiring of digital and analog inputs/outputs with function "Safe torque off" deactivated, given an
external voltage source
S1 Controller enable
NO contact or NC contact
Z Load
Minimum wiring required for operation
Terminal assignment in the Lenze setting: ^ 97
