Scope of supply
Description
Use
Amount
0
9300 vector frequency inverters
1
1
Mounting Instructions
1
2
Mounting rail
2
^ 78
3
Hexagon socket screw M8 × 25 mm
Fastening of the controller with mounting rails
2
on the mounting plate
12
4
Spring washer M8
12
5
EMC shield sheet for shielded control cables
1
^ 91
6
Recessed head screw M4 × 12 mm
Fastening of EMC shield sheet
5
2
7
Shield clip
Connection of the cable shields to the shield sheet
3
8
Terminal strip, 4−pole
Safety relay K
SR
at X11
1
^ 92
9
Terminal strip, 7−pole
Digital inputs and outputs at X5
2
^ 92
:
Terminal strip, 4−pole
Analog inputs and outputs at X6
2
^ 92
;
Terminal strip, 3−pole
System bus (CAN) at X4
1
^ 98
<
Protective cover
Protection for unused Sub−D sockets
4
Connections and interfaces
Description
Function
Power terminals
Controller mains connection for 400 V
^ 82
Controller mains connection for 500 V
^ 83
Power terminals
Connection to the DC bus
^ 84
Power terminals
Motor connection
^ 87
x1
Control interface
Plug−in station, e.g. for keypad
X3
Jumper
Setting of analog input signal at X6/1, X6/2
^ 97
X4
Control terminals
System bus (CAN)
^ 98
X5
Control terminals
Digital inputs and outputs
^ 90
X6
Control terminals
Analog inputs and outputs
^ 90
X8
Sub−D socket
Incremental encoder input
^ 100
X9
Sub−D socket
Incremental encoder input
^ 101
Digital frequency input
^ 102
X10 Sub−D socket
Digital frequency output
^ 102
X11 Control terminals
Safety relay K
SR
^ 92
Status displays
Position
LED red
LED green
Operating status
Off
On
Controller is enabled
On
On
Mains is switched on and automatic start is inhibited
Off
Blinking slowly
Controller is inhibited
Off
On
Motor data identification is active
Blinking quickly
Off
Undervoltage or overvoltage
Blinking slowly
Off
Active fault
