13 Parameter reference
13.3 Parameters of the communication module for slot MXI2
70
Lenze · E94AYCIB communication module (INTERBUS) · Communication Manual · DMS 4.0 EN · 02/2014 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C14901
C14902
C14920
Parameter | Name:
C14901 | Firmware compilation date
Data type: VISIBLE_STRING
Index: 9674 = 0x25CA
Display of the compilation date of the firmware (string with a length of 20 bytes)
• The date ("MMM TT JJJJ") and the time ("hh:mm:ss") are output, e.g. "Mar 21 2005 12:31:21".
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14902 | Firmware version
Data type: VISIBLE_STRING
Index: 9673 = 0x25C9
Display of the firmware version (string with a length of 8 bytes)
The identification code is output, e.g. "01.00.00".
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14920 | Display of DIP switch position
Data type: BITFIELD_8
Index: 9655 = 0x25B7
Display of the current DIP switch position
• The set parameter data length (PCP) is displayed in C13860/1 .
• The set process data length is displayed in C13860/2 .
• The set baud rate is displayed in C13863 .
 Possible settings via DIP switch ( 30)
Value is bit-coded: Info
Bit 0 DIP 8 Baud rate
Bit 1 DIP 7 No response
Bit 2 DIP 6 Number of parameter data words (PCP)
Bit 3 DIP 5
Bit 4 DIP 4
Number of process data words
Bit 5 DIP 3
Bit 6 DIP 2
Bit 7 DIP 1
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
