13 Parameter reference
13.2 Parameters of the communication module for slot MXI1
58
Lenze · E94AYCIB communication module (INTERBUS) · Communication Manual · DMS 4.0 EN · 02/2014 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13855
C13860
C13861
Parameter | Name:
C13855 | Length of ports mapped into send PDO
Data type: UNSIGNED_8
Index: 10720 = 0x29E0
Display of the total data length (in bytes) of the ports that have been entered into the send PDO.
The data word sum (process data words + parameter data words) has to consist of 1 ... 10 words (16 bits/word).
 Configuring process data (PDO mapping) ( 37)
Display area (min. value | unit | max. value)
0 64
Subcodes Info
C13855/1 Length of the ports entered into the send PDO
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13860 | Settings
Data type: UNSIGNED_8
Index: 10715 = 0x29DB
Display of the set number of the
• Parameter data words
• Process data words
The data word sum (process data words + parameter data words) has to consist of 1 ... 10 words (16 bits/word).
Display area
(min. value | unit | max. value)
0 10
Subcodes Info
C13860/1 Display of parameter data length (PCP)
C13860/2 Display of process data length
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13861 | Bus status
Data type: BITFIELD_16
Index: 10714 = 0x29DA
Display of the current bus status
Meaning of the resulting hexadecimal values:
• 0xyyy0 = IBS-INIT
• 0xyyy1 = IBS-ACTIVE
• 0xyyy2 = IBS-READY
 Querying the current bus status ( 48)
Value is bit-coded: Info
Bit 0 Bit 0
... ...
Bit 15 Bit 15
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
