13 Parameter reference
13.2 Parameters of the communication module for slot MXI1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13852
C13853
C13854
Parameter | Name:
C13852 | All words to the basic device
Data type: UNSIGNED_16
Index: 10723 = 0x29E3
Display of the process data words which are transmitted from the communication module to the standard device.
• In the subcodes 1 ... 32, all process data words from the communication module are displayed.
Display area (min. value | unit | max. value)
0 65535
Subcodes Info
C13852/1
...
C13852/32
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13853 | All words to the basic device
Data type: UNSIGNED_16
Index: 10722 = 0x29E2
Display of the process data words which are transmitted from the standard device to the communication module.
• In the subcodes 1 ... 32, all process data words from the standard device are displayed.
Display area
(min. value | unit | max. value)
0 65535
Subcodes Info
C13853/1
...
C13853/32
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13854 | Length of ports mapped into receive PDO
Data type: UNSIGNED_8
Index: 10721 = 0x29E1
Display of the total data length (in bytes) of the ports that have been entered into the receive PDO.
The data word sum (process data words + parameter data words) has to consist of 1 ... 10 words (16 bits/word).
 Configuring process data (PDO mapping) ( 37)
Display area (min. value | unit | max. value)
0 64
Subcodes Info
C13854/1 Length of the ports entered into the receive PDO
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
