Page 43
Lenze · E94AYCIB communication module (INTERBUS) · Communication Manual · DMS 4.0 EN · 02/2014 · TD17
43
9
Parameter data transfer
9.3
Supported PMS services
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
9.3.6
Identify
The P "Identify" MS service provides information on how to identify the inverter.
The inverter with the plugged-on communication module provides the following parameters for
this:
Example: Visible string "device type" (15 characters)
Example: Visible string "device version" (15 characters)
Parameter
Type
Description
Device manufacturer
Visible string
Company name "Lenze"
Device type
Visible-string (15 characters) Device name for inverter and communication
module
Device version
Visible-string (15 characters) Firmware version of the inverter and the
communication module
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
E
9
4
A
F
H
B
A
F
C
I
B
Character
Description
1 ... 3
Product range of the inverter and the communication module ("E94" = 9400 series)
4
Blank
5 ... 8
Firmware of the inverter (from C00200/0)
• Character 5: Version ("A" = 1st generation)
• Character 6 ... 8: Firmware version
• "FHB" = Servo Drive 9400 HighLine
• "FRB" = Servo Drive 9400 regenerative power supply module
• "VPB" = Servo Drive 9400 PLC
9
Blank
10 ... 14
Firmware of the communication module (from
/
)
• Character 10: Version ("A" = 1st generation)
• Characters 11 ... 14: Firmware version
• "FCIB" = INTERBUS module
15
Blank
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
0
5
.
0
0
0
1
.
0
0
Character
Description
1 ... 5
Firmware version of the inverter (from C00099/0 = "05.00.xx.yy", without internal revision status
["xx"] and build status ["yy"])
6
Blank
7 ... 11
Firmware version of the communication module (from
/
= "01.00.xx", without
internal revision status ["xx"])
12...15
Blank
