Page 55: 13 parameter reference

Lenze · E94AYCIB communication module (INTERBUS) · Communication Manual · DMS 4.0 EN · 02/2014 · TD17
55
13
Parameter reference
13.2
Parameters of the communication module for slot MXI1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
13.2
Parameters of the communication module for slot MXI1
This chapter lists the parameters of the E94AYCIB communication module (INTERBUS) for slot MXI2
of the Servo Drive 9400 in numerically ascending order.
C13231
C13489
C13531
Parameter | Name:
C13231 | Service code
Data type: UNSIGNED_64
Index: 11344 = 0x2C50
This code is for device-internal use only and must not be written to by the user.
Value is bit-coded:
Info
Bit 0 Bit 0
... ...
Bit 63 Bit 63
Subcodes
Lenze setting
Info
C13231/1
0
...
...
C13231/32
0
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13489 | Service code
Data type: UNSIGNED_8
Index: 11086 = 0x2B4E
This code is for device-internal use only and must not be written to by the user.
Setting range
(min. value | unit | max. value)
0
32
Subcodes
Lenze setting
Info
C13489/1
0
Service code
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13531 | Service code
Data type: UNSIGNED_64
Index: 11044 = 0x2B24
This code is for device-internal use only and must not be written to by the user.
Value is bit-coded:
Info
Bit 0 Bit 0
... ...
Bit 63 Bit 63
Subcodes
Lenze setting
Info
C13531/1
0
...
...
C13531/32
0
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
