13 Parameter reference
13.3 Parameters of the communication module for slot MXI2
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C14852
C14853
C14854
Parameter | Name:
C14852 | All words to standard device
Data type: UNSIGNED_16
Index: 9723 = 0x25FB
Display of the process data words 1 ... 32 transferred from the communication module to the standard device.
• In the subcodes 1 ... 32, all process data words from the communication module are displayed.
Display area (min. value | unit | max. value)
0 65535
Subcodes Info
C14852/1
...
C14852/32
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14853 | All words from standard device
Data type: UNSIGNED_16
Index: 9722 = 0x25FA
Display of the process data words 1 ... 32 transferred from the standard device to the communication module.
• In the subcodes 1 ... 32, all process data words from the standard device are displayed.
Display area
(min. value | unit | max. value)
0 65535
Subcodes Info
C14853/1
...
C14853/32
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14854 | Length of ports mapped into receive PDO
Data type: UNSIGNED_8
Index: 9721 = 0x25F9
Display of the total data length (in bytes) of the ports that have been entered into the receive PDO.
The data word sum (process data words + parameter data words) has to consist of 1 ... 10 words (16 bits/word).
 Configuring process data (PDO mapping) ( 37)
Display area (min. value | unit | max. value)
0 64
Subcodes Info
C14854/1 Length of the ports entered into the receive PDO
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
