13 Parameter reference
13.2 Parameters of the communication module for slot MXI1
56
Lenze · E94AYCIB communication module (INTERBUS) · Communication Manual · DMS 4.0 EN · 02/2014 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13789
C13850
C13851
Parameter | Name:
C13789 | Service code
Data type: UNSIGNED_8
Index: 10786 = 0x2A22
This code is for device-internal use only and must not be written to by the user.
Setting range
(min. value | unit | max. value)
0 32
Subcodes Lenze setting Info
C13789/1 0 Service code
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13850 | All words from drive to master
Data type: UNSIGNED_16
Index: 10725 = 0x29E5
Display of the process data words which are transmitted from the communication module to the master.
• In the subcodes 1 ... 32, all process data words to the master are displayed. Only the configured process data
words are valid.
Display area (min. value | unit | max. value)
0 65535
Subcodes Info
C13850/1
...
C13850/32
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13851 | All words from master to drive
Data type: UNSIGNED_16
Index: 10724 = 0x29E4
Display of the process data words which are transmitted from the master to the communication module.
• In the subcodes 1 ... 32, all process data words to the master are displayed. Only the configured process data
words are valid.
Display area (min. value | unit | max. value)
0 65535
Subcodes Info
C13851/1
...
C13851/32
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
