Commissioning

Code

Possible Settings

IMPORTANT

No.

Name

Default Selection

P708

Sequencer: Time
units/scaling

0 0.1

{sec}

6553.5

Setup units/scaling for all sequencer time
related parameters

1 1

{sec}

65535

2 1

{min}

65535

NOTE:
P708 rescales the following sequencer related parameters:

- Segment Times in current step: P712, P717, P722, P727, P732, P737, P742, P747,

P752, P757, P762, P767, P772, P777, P782, P787, P792

- Sequence diagnostic/status: P561, P562

Segment #1

P710

Segment #1
Frequency Setpoint

0.0

-500.0 {Hz} 500.0

If P112 = 1, negative sign forces reverse
direction

P711

Segment #1
Accel/Decel Time

20.0

0.0

{sec} 3600.0

P712

Segment #1
Time in current step

0.0

{P708} 6553.5

{P708} 65535

Scaling/units depend on P708
Skip segment if time = 0

P713

Segment #1
Digital Output State

Value set in P713

0 1 2 3 4 5 6 7

Relay (Bit 0)

0 1 0 1 0 1 0 1

TB14 (Bit 1)

0 0 1 1 0 0 1 1

I/O option Relay (Bit 2)

0 0 0 0 1 1 1 1

NOTE: P441 is the Relay Output (TB-19, 20, 21) of the
optional Digital I/O module (ESVZAL0, ESVZAL1).

bit = 0: OFF (De-energized)
bit = 1: ON (Energized)
The corresponding digital output/relay must be
set to accept data from the sequencer: P140,
P142, P441 = 27

P714

Segment #1 TB30
Analog Output
Value

0.00

{VDC} 10.00

TB30 configuration parameter must be set to
accept this value: P150 = 10

Segment #2

P715

Segment #2
Frequency Setpoint

0.0

-500.0 {Hz} 500.0

If P112 = 1, negative sign forces reverse
direction

P716

Segment #2
Accel/Decel Time
