CHAPTER 5: Module Installation
45
cover. The delicate metallic finger stocks are located
at the front and rear of the cover. They are needed
to make contact with the bottom enclosure and to
ensure compliance with FCC Part 15 or FTZ
radiated emission standards. 5.5.3 R EMOVE B LANK B ACK P ANELS
Each blank back panel is supported by two retaining
screws. To remove the panel, unscrew and remove
the screws. Then pull off the panel.
Remove all blank back panels down to the top
module board.
Figure 5-8. Remove any blank panels.
NUMBER 1
SPACER
Figure 5-9. Remove spacers.
