Multiserver 5000
210
Figure B-13. Tandem Cable Diagram.
Cabling for Use with Tandem
1
2
3
4
5
6
7
8
20
22
25
1
2
3
4
5
6
12
7
8
20
22
25
25-PIN CONNECTOR
(MALE)
25-PIN CONNECTOR
(FEMALE)
CONNECTS TO
TANDEM CPU
BUSY
RING ADAPTER
DATA TERMINAL READY
DATA CARRIER DETECT
GROUND
T-PAUSE
DATA SET READY
CLEAR-TO-SEND
REQUEST-TO-SEND
RECEIVED DATA
TRANSMITTED DATA
NOT USED
TO MULTISERVER
