CHAPTER 3: Network Design and Topologies
33
D
ISTRIBUTED
S
TAR
If two Multiserver star networks are connected, the topology can be described as a distributed star.
Figure 3-10 shows two star networks connected to form a distributed star.
MULTISERVER
5000
MULTISERVER
1000
FEEDER MUX
MULTISERVER
1000
FEEDER MUX
MULTISERVER
1000
FEEDER MUX
MULTISERVER
1000
FEEDER MUX
Figure 3-10. Typical Distributed-Star Application.
