CHAPTER 4: Base-Unit Installation

37

4.6 Identify the Module Locations and

Channel Numbers

M

ODULE

L

OCATION AND

N

OMENCLATURE

There are five chassis positions available for
modules in the Multiserver 5000. These are
identified from bottom to top as module locations
A through E.

• The Communications Control Module (CCM) is

always in module location A.

• A space is reserved below the CCM for the

optional NMS module. Its module location
is “$.” Note that there is no “$” printed on the
rear-panel of the Multiserver 5000.

• Optional modules can fill module locations B

through E.

C

HANNEL

L

OCATION AND

N

OMENCLATURE

Channel numbers are assigned to all the ports on

Table 4-1. CCM Indicator LEDs

INDICATOR STATUS

EQUIPMENT STATUS

AT

BO

A6

A5

A4

A3

A2

A1

1

0

X

X

X

X

X

X

1

Normal equipment status

0

0

1

0

0

0

0

0

ROM Test Failure (CommPak cartridge
failure)

0

0

0

0

0

0

0

1

CMOS Failure

2

0

0

0

0

0

0

1

0

Battery low

3

0

1

1

0

0

0

0

0

RAM Failure in CommPak cartridge

1

0

1

0

1

0

1

0

Parity error

1

1

1

1

1

1

1

1

CommPak cartridge not installed
properly or defective Multiserver unit

0

1

0

0

0

0

0

0

RAM Test Failure (CCM)

KEY
0 = LED off
1 = LED on
X = LED can be off or on. This will change as the status of the port activity changes.

1

If A1 is configured as a link, it blinks on power-up with no established link. (The default setting is for A1 to be
configured as a link.)

2

System can still operate with CMOS failure. All configuration data has been lost in the affected CMOS section,
and default values have been supplied.

3

System can still operate with a low battery. Configuration data may be lost if the Multiserver loses power.
