Multiserver 5000
232
ni TRANSMITTER RING Event A call is coming in on the transmitter side.
DETECT LINK ci
ni TX CONNECTION MADE Event A successful call was placed over the dial-lines
LINK # ci from the modem’s TX dial line connection. This
message is displayed by the call-originating modem.
Dialog • Node, class, module location, or port is unknown
in the network.
• Password for the class may be incorrect.
• If matrix switching is disabled, this message will
display when matrix switching is attempted.
Dialog Requested resource exists, but is not in service (not
operational). Call inhibit may be off or DTR is off.
VOICE CHANNEL Event Voice/fax port c on node n has been put in a
[ n/c] [condition] busyout state. [Conditions] may be the
BUSY OUT following:
System Where the link has experienced a sync
loss, a force-disable command, or a
force-disconnect command.
Forced Where the network operator has put the
channel in a busyout condition via a
forced-busy command.
VOICE CHANNEL [ n/c] Event Termination of a busyout condition has
BUSYOUT CLEARED occurred on voice/fax channel c.
VOICE CHANNEL [ n/c] Event The current dBm level for voice/fax port
INPUT LEVEL: nn dBm c on node n is nn (-25 to +1) dBm.
- [ display] - Note: [Display] is a dynamic display
which appears on the screen.
VOICE CHANNEL [ n/c] Diagnostic Voice/fax port c on node n has started the
LOCAL LOOP TEST diagnostic local loop test.
VOICE CHANNEL Event The voice/fax port has been reset and
[ n/c] RESET re-initialized to the current configuration.
VOICE CHANNEL [ n/c] Diagnostic Voice/fax port c on node n has completed
SELF TEST FAIL the internal diagnostic tests unsuccessfully.
VOICE CHANNEL [ n/c] Diagnostic Voice/fax port c on node n has completed
SELF TEST PASS the self-tests successfully.
Screen Display Messages
Message Message Type Explanation
