Appendix B: Cabling Diagrams
193
Figure B-1. To DTE, Male-to-Male Straight Cable
(EZ422-0015).
Cabling for the CCM and 6-Channel CEMs (continued)
1
2
3
4
5
6
7
8
11
15
17
18
20
22
24
25
1
2
3
4
5
6
7
8
11
15
17
18
20
22
24
25
25-PIN CONNECTOR
(MALE)
25-PIN CONNECTOR
(MALE)
TO MULTISERVER
TO DTE
BUSY
EXTERNAL TRANSMIT CLOCK
RING INDICATOR
DATA TERMINAL READY
EXTERNAL RECEIVE CLOCK
RECEIVE CLOCK
TRANSMIT CLOCK
UNASSIGNED
CARRIER DETECT
SIGNAL GROUND
DATA SET READY
CLEAR-TO-SEND
REQUEST-TO-SEND
RECEIVE DATA
TRANSMIT DATA
PROTECTIVE GROUND
PIN 1
