CHAPTER 11: Administration
149
5. Voice/Fax Status If the Multiserver is equipped with a voice/fax module, this option will display a range of
ports selected, the input level, the mode (on hook, off hook, busy), the software
revision, and, if applicable, the test mode and test status.
When this options is selected, the following prompt appears:
ENTER NODE-ID/CHANNEL # (OR RANGE OF CHANNELS)(^X TO ABORT):
Enter the node ID, a slash, and the channel number (or range of channels). Press
. The voice/fax channel status will display on the screen. See the MS1 Voice/Fax
Card User’s Manual for more information.
6. Integral Device If the Multiserver is equipped with an integral device, this option will display the status
Status report of the leased line and dial backup activity. When this option is selected, the
following prompt appears:
ENTER LINK CHANNEL # (^X TO ABORT):
Enter the port number of the link. Press . A Leased Dial Line Status is displayed.
[node id] LAST PERIOD REPORT (1) TIME hh:mm:ss DATE mm/dd
SYSTEM STATISTICS (INTERCONNECT LINK A01):
--------------------------------------------------------------
TRANSMITTED RECEIVED
FRAME COUNT (X100): 0 0
LOCAL (2)
UTILIZATION % = COMPOSITE 20
BUFFERS 57
EVENT COUNTS (X1) = RETRANSMITS 0
LINE ALARMS 0
TIME (SECONDS) IN = SYS FLOW CTL 0
SYNC LOSS 1
CD LOSS 1
ENTER CARRIAGE RETURN TO CONTINUE
(1)
The format for the Last Period Report and the
Demand Report are the same.
(2)
No remote status is shown for interconnect links.
