Black Box 5000 - Manual (Page 204)

Multiserver 5000
202
12-CHANNEL CEM
WITH LINE DRIVER
(DCE)
BLACK
RED
GREEN
YELLOW
RX+
RX-
TX-
TX+
TX+
TX-
RX-
RX+
1
2
3
4
5
6
7
8
RJ-45
PIN ASSIGNMENTS
RS-422
CUSTOMER
EQUIPMENT
BLACK
RED
GREEN
YELLOW
RX+
RX-
TX-
TX+
TX+
TX-
RX-
RX+
1
2
3
4
5
6
7
8
RJ-45
PIN ASSIGNMENTS
RS-423
CUSTOMER
EQUIPMENT
(DATA IN)
PIN 1
RJ-45
Cabling for the 12-Channel CEM with Line Drivers
