Multiserver 5000
146
11.6 Status/Statistics
Status and statistics reports are available on the
Status/Statistics Menu. Status is a snapshot of the
system as it appears the moment the request is
made; statistics are a readout of the system within a
defined period of time.
You will use the Status/Statistics menu often to
monitor your network’s operation.
To access the Status/Statistics Menu, select option 2
on the Command Facility Main Menu.
The Status/Statistics menu appears. Each of the
menu options is discussed in Table 11-7.
COMMAND FACILITY MAIN MENU [node id]
STATUS/STATISTICS 2
STATUS/STATISTICS [node id]
1. NODE STATUS
2. CHANNEL STATUS
3. INTERFACE STATUS
4. QUEUE STATUS
5. VOICE/FAX STATUS
6. INTEGRAL DEVICE STATUS
7. SYSTEM STATISTICS
8. CHANNEL STATISTICS
9. SWITCH STATISTICS
10. PROM ID
11. VOICE/FAX DAILY STATISTICS
12. NETMan STATUS
CR - ACCEPT ENTRY
M - MAIN MENU
ENTRY:
Table 11-7. Status/Statistics
Option Description
1. Node Status Displays the current node IDs, node numbers, link ports, and link type for each unit
connected directly to the local Multiserver unit. It also lists all available nodes on the full
network. See Section 8.9, Review Link Configuration, for a sample display.
2. Channel Status Displays the current voice/fax and data channel status of a range of ports, the speed,
and the node ID/channel number of any connection.
When you select this option, the following prompt displays:
ENTER NODE-ID/CHANNEL# (OR RANGE OF CHANNELS)(^X TO ABORT):
Enter the node ID/channel number (or range of channels). Press . The Channel
Status screen appears (see next page).
