SQM-242 Operating Manual
2.2 SQM-242 Driver Installation
1
Turn on the computer and start Windows. Windows will find new hardware and
prompt to Install Device Drivers.
2
If you are prompted for the location of the Device Drivers, insert the INFICON
CD-ROM and direct Windows to D:\SQM242 Card\SQM242_V100_DRIVERS
(assuming D is your CD drive).
3
When driver installation is complete, you may be prompted to restart your
computer.
4
Check the README.txt file in the \SQM242 Card\SQM242_V100_DRIVERS
folder of the INFICON CD-ROM for additional steps that are specific to your
version of Windows.
5
Verify that the card was installed properly in Device Manager. Right-click on My
Computer, then left-clicking on Properties. Click on the Device Manager tab
(Hardware tab in Windows 2000 or XP, then Device Manager). You should see
Sigma Instruments listed, with the SQM-242 cards in the sub folder.
If the card is not listed (or has a red x or yellow exclamation point), repeat the
installation procedures above carefully.
NOTE: Occasionally it may be necessary to completely uninstall and reinstall a
card. Highlight the improperly installed card in Device Manager and press
Card\SQM242_V100_DRIVERS folder of the INFICON CD-ROM. Reboot
the computer, then follow the steps above carefully.
2.3 Software Installation
SQM-242 Card programs are also on the INFICON CD-ROM. Insert the CD-ROM,
click the Windows Start button, and then select Run. Type D:\SQM242
Card\Setup.exe and click OK.
Accept the default installation prompts. When installation completes, you may be
prompted to restart your computer. This installer will install three programs:
SQM-242 CoDep, SQM-242 Monitor, and SQM-242 Multi.
To run the any software program, click Start, then Program, then Sigma
Instruments and select the program.
To verify the SQM-242 cards are properly installed, start SQM-242 CoDep. Select
the View menu, then Card Setup. If the card revision for each installed card is
greater than 0.00, then it is installed properly.
NOTE: If the version is shown as 0.00, then reinstall the Windows drivers as
. Pay particular attention to any Windows version
specific instructions in the README file.
