9-4

Technical Data

jinb

80

e1

-h

Op

er

at

in

g M

a

nua

l

(1

01

1)

ZERO

Edge-controlled input

Change from LOW to HIGH: Activate ZERO.

Change from HIGH to LOW: Deactivate ZERO

START/STOP

Edge-controlled input

Change from LOW to HIGH: activate START

Change from HIGH to LOW: activate STOP

START

Edge-controlled input

Change from LOW to HIGH: carry out START

STOP

Edge-controlled input

Change from LOW to HIGH: activate STOP

If this input is HIGH for a longer period than it is set in "Ventilation Delay", ventilate
additionally.

VENT

Edge-controlled input

Change from LOW to HIGH: Flooding

GAS BALLAST

Edge-controlled input

Change from LOW to HIGH: Activate Gas Ballast/Purge.

Change from HIGH to LOW: Deactivate Gas Ballast/Purge.

CLEAR

Edge-controlled input

Change from LOW to HIGH: Acknowledge error message or abortion of a calibration.

CAL

Edge-controlled input

Change from LOW to HIGH:

In case the device is in Standby mode: Start internal automatic calibration. In case
the machine is in Measurement mode: Start manual calibration. (Precondition: exter-
nal test leak has to be open and leak rate signal is constant)

Change from HIGH to LOW:

External calibration: approve that external test leak is closed and leak rate signal is
stable.
