Error Messages and Warnings

10-3

jinb

80

e1

-h

Op

er

at

in

g M

a

nua

l

(1

01

2)

E34

24 V voltage at MSV board is
too low!

Signal MVPZN on the MSV board is active. 24 V voltage on the MSV board is too
low, U <18.3 V.

Fuse F1 on the MSV board has burned through.

Reference voltage UREF on the MSV board XT7/1 is too high, U>5 V.

DC/DC transformer of MSV board is defective

24 V current supply from the main power supply unit is excessively strained or
defective.

E35

Anode - cathode voltage is too
high!

Anode-cathode voltage is higher than U > 130 V.

MSV is faulty.

E36

Anode - cathode voltage is too
low!

Anode-cathode voltage is lower than U < 30 V.

Fuse F4 on the MSV board is defective.

MSV is faulty.

E37

Reference size of suppressor
voltage is too great.

Signal MFSZH on MSV board is active. Suppressor signal control input is too high.

Suppressor voltage is short circuited (cable, ion accumulator)

MSV is faulty.

E38

Suppressor potential is too high.

Suppressor potential is greater than 363V.

MSV is defective.

E39

Suppressor potential is too low.

Suppressor potential is lower than U < 297 V.

Short circuit in suppressor line.

MSV is faulty.

High-impedance short circuit in the ion collector.

E40

The anode potential exceeds
the target value by more than
10%.

The actual anode potential exceeds its nominal value by 10%. The nominal value
can be displayed in the service menu (in "Info")

MSV is faulty.

MC 68 is defective

E41

The anode potential falls below
the target value by more than
10%.

The actual anode potential has dropped below its nominal value by 10%. The
nominal value can be displayed in the service menu (in "Info")

Brief pressure increase in the mass spectrometer.

MSV is faulty.

MC 68 is defective

E42

Target value of the anode
potential is too high.

Signal MFAZH on MSV board is active. Reference size of the anode potential is
too great.

Brief pressure increase in the mass spectrometer.

Valve contamination causes briefly a high mass spectrometer pressure.

Anode voltage has been short circuited.

Nominal value of the anode voltage is too high. Anode voltage is limited to about
1,200 V.

E43

Cathode current is too high.

Signal MPKZH on MSV board is active. Cathode current is too high, I >3.6 A.

MSV board is defective.

No.

Displayed Message

Description and possible solutions
