6 operation, 1 switching on, 2 status led – INFICON Helium Leak Detector Modul1000 User Manual
Page 42: Switching on, Status led, 6operation

6-1
Operation
jinb
80
e1
-h
Op
er
at
in
g M
a
nua
l
(1
01
2)
6
Operation
6.1
Switching ON
Install the device as described in the Installation chapter. Connect the power cable.
Switch the device ON. The mains switch and the connection for the power cable are
at the back of the device.
After the mains switch has been actuated the devices runs up automatically.
In run-up mode (
≤ 3 Min.) the following items appear on the display:
•
Speed of the turbo-molecular pump
•
Fore-vacuum pressure
•
State of emission
•
Active filament
•
A bar graph which shows the run-up progress
After the run-up has been completed, the Modul1000 is in „Standby“ mode.
6.2
Status LED
The LEDs show the operating mode of the device:
Operating mode:
LED, green
LED, yellow
Run-up
Flashes
Flashes
Standby/Vent
On
Off
Evacuate
On
Flashes slowly
Measuring
On
On
Calibrating
Flashes synchronously
Flashes synchronously
Error / Warnings /
Maintenance messages
Off
Flashes fast
