INFICON Helium Leak Detector Modul1000 User Manual
Page 66

6-25
Operation
jinb
80
e1
-h
Op
er
at
in
g M
a
nua
l
(1
01
2)
Main Menu
→
Settings
→
Interfaces
→
External Pressure Gauge
In Commander mode, the Modul1000 has to be connected to an external pressure
gauge. In the "External pressure gauge" mode is for setting the characteristics and
the zero-point, as well as full scale of the used pressure gauge.
Main Menu
→
Settings
→
Interfaces
→
Define PLC Outputs
In this sub-menu, the pin assignment of the PLC output connector (PLC-OUT) can
be changed.
To assign the PLC outputs proceed as follows:
1
Select the connecting pin of the connector PLC-OUT to be changed using the left
arrow key
2
The right arrow key serves for assigning the selected pin to one of the listed
functions.
3
After the PLC outputs have been assigned as desired, confirm the settings by
pressing the OK button.
Main Menu
→
Settings
→
Interfaces
→
Define PLC Inputs
In this sub-menu, the pin assignment of the PLC input connector (PLC-IN) can be
changed.
To assign the PLC inputs proceed as follows:
1
Select the connecting pin of the connector PLC-IN to be changed using the left arrow
key
2
The right arrow key serves for assigning the selected pin to one of the listed
functions.
3
After the PLC inputs have been assigned as desired, confirm the settings by pressing
the OK button.
The PLC inputs and the PLC outputs can be inverted in the menu via the serial inter-
face. The inverting is also be saved in the parameter sets.
Main Menu
→
Settings
→
Interfaces
→
Recorder
In this sub-menu, the signals to be recorded by the recorder can be assigned to the
two recorder outputs (analogue outputs).
→
Recorder output
Refer to chapt. 9.4 Analogue output (Recorder output).
→
Characteristics:The following characteristics can be set: current linear, voltage
linear, current logarithmic, voltage logarithmic.
→
Zero point:
The zero point (pressure value) of the connected sensors can be
assigned with the corresponding current or voltage value.
→
Full scale:
The full scale (pressure value) of the connected sensors can be
assigned with the corresponding current or voltage value.
