GSM Radio Module CSI-F-10 Page 46
Status 29.01.2009 HYDAC ELECTRONIC GMBH Part.-Nr.: 669752
• Make the corresponding preselection for the port settings in the window that
opens under Interface selection.
• Select the relevant port address and Baud rate (9600 for GSM) under Interface
settings .
• Click "Refresh" to update the interfaces marked under Interface selection in
terms of availability.
• Click on “OK“ to apply the modified settings or “Cancel“ to discard these
changes. In either case you will then return to the Connection window.
• Click on "Modify" in the Telephone number line to open the window for
inputting telephone numbers.
• Enter the telephone number of the SIM card mounted in the GSM module CSI-
F-10.
• In the Pin field enter the PIN code (if one has been assigned) for the SIM card
of the modem connected to the PC. If no PIN code has been assigned, then
leave the field empty.
• You can set up a list of telephone numbers (address book) under Telephone
list
.
• Click on “OK“ to apply the entries or “Cancel“ to discard these changes. In
either case you will then return to the Connection window.
Telephone number of the
SIM card in the CSI-F-10
PIN number of the SIM-
card in the PC modem
