GSM Radio Module CSI-F-10 Page 19
Status 29.01.2009 HYDAC ELECTRONIC GMBH Part.-Nr.: 669752
In total
max. 40m
HSI Address "b"
5 pole, max. 30m
5 pole, max. 30m
8 pole, max. 30m
A
ZBE 41
B
5.3.2 AS 1000 to Connection 1 and CS 1000 to Connection 2
ZBE 38
ZBE 36
HSI Address "a"
Voltage supply / HSI
see Chap. 6.3 to 6.6
In this case, only voltage
supply for CS 1000!
