GSM Radio Module CSI-F-10 Page 108
Status 29.01.2009 HYDAC ELECTRONIC GMBH Part.-Nr.: 669752
9.10 Actions
9.10.1 Setting Switching Output
The Set switch output function transmits the Boolean input to a
digital switching output on the CM device.
The Output terminal parameter is used to define which digital output
port is used.
Inputs: x: (Boolean)
Outputs: -
Parameters: p
1
: Output terminal (input list)
9.10.2 Switch on LED
The Switch on LED function has one Boolean input. The relevant
LED will remain on for as long as the input value is "1".
The Acknowledge parameter is disregarded on the CSI-F-10
platform because this device does not have the facility to
acknowledge LEDs as it does not have the required buttons.
Each LED may only be used once in the CM program.
Depending on the precise CM device, the LEDs can have different
designations, e.g.: red, green, LED1, LED2, etc.
Inputs: x: (Boolean)
Outputs: -
Parameters: p
1
: Color (entry list)
p
2
: Acknowledgement (Boolean)
9.10.3 Send SMS
The Send SMS function is used to send an SMS when an event
occurs. This occurs every time the input value changes from "0" to
"1".
The text of the SMS is defined with the Message parameter and the
Telephone number
parameter defines the number to which the SMS
is sent.
Inputs: x: (Boolean)
Outputs: -
Parameters: p
1
: Telephone number (character string)
p
2
: Message (character string)
