GSM Radio Module CSI-F-10 Page 114
Status 29.01.2009 HYDAC ELECTRONIC GMBH Part.-Nr.: 669752
11 Specifications
11.1 Power Supply
- Input voltage:
10.5 ... 35.0 V DC
- Residual ripple:
≤ 5 %
- Current consumption without sensors and outputs:
Typical (mean value): ≤ 90 mA Stand-By / ≤ 200 mA with radio connection
Pulsed: ≤ 2 A (power supply recommendation: 3.5 A)
- Reverse voltage protection:
-35 V
11.2 Sensor Inputs
(5 pole female connection "Sensor 1", 8 pole female connection "Sensor 2")
A maximum of 2 SMART sensors can be connected.
- Output voltage (+U
B out
): +U
B in
– 0.5V
- Current supply:
max. 500mA at 50°C
11.3 Logic measurement channels
A total of up to 32 measurement channels can be processed by the CSI-F-10.
A measurement channel can be a sub-channel of a SMART sensor or a value derived
(calculated) from sensor data.
11.4 Digital Inputs and Outputs (8 pole female connection "In/Out")
- Output voltage (+U
B out
): +U
B in
– 0.5 V
- Current supply (incl. outputs): max. 500 mA at 50 °C
- Inputs
Quantity: 4
Input voltage: 0 ... 35.0 V DC
Trigger threshold: Low: < 0.8 V; High: > 5.0 V
Input current consumption: approx. 4 mA
- Outputs
Quantity: 2
Switching capacity (per output): + U
B Out
/ 0.2 A
11.5 Interfaces
HSI bus
Mobile radio network: GSM 850 / 900 (2W (EGSM))
GSM 1800 / 1900 (1W (EGSM))
Antenna 50 Ω FME plug
SIM: 3V SIM card
