18 Unison Paradigm Touchscreen User Manual
Saving and Loading Configuration Files
Saving and loading configuration and theme files is simple.
Step 1: To begin, you must have an USB key or SD card (your choice) inserted into the
port receptacle of the Touchscreen.
Step 2: Select either [Config] or [Theme] (whichever file type you want to transfer).
Step 3: If saving a file to removable media select the file from the list and press [Save
to]. If loading a file from removable media, press [Load From].
Step 4: Choose the removable media (SD or USB) you are transferring to/from.
Step 5: Navigate the file structure of the removable media to select the location you are
saving to/loading from. To return to a previous directory in the removable media,
press the [Up] button. Press [Ok] to set the directory location.
Network tab
The “Network” tab provides access to view and edit the network address settings for the
Touchscreen. The Touchscreen ships with the defaults displayed in the image above.
N o t e : Multiple files can be selected for upload or download by simply touching to select
each file. When a file with the same name exists at the save to location or if it
already exists on the Touchscreen when loading from removable media, you will
be prompted to either [Cancel] the action or [Overwrite] the existing conflicting
file.
