Machine overview – ERICO ELAT100 LENTON Automatic Threader User Manual
Page 3
www.erico.com
3
Threader – Front View
Threader – Control Panel Side
Machine Overview
Threader – Side View
Operator
Station
Impact
Wrench
Electrical
Control Panel
Bar End
Adjustment
Cycle Start Sensor
(Normally Closed)
Step Down
Transformer
Outer Limit + Reference Sensors
(Normally Open)
Kill Switch
DC Proximity Switch
Spindle Proximity Switch
DC Motor
