HY[N] - Auxiliary Homing, Capture and Flag
Purpose:
Sets the parameters of the auxiliary homing and capture process, by which the
SimplIQ
sets a trap for a user-defined event. When the event occurs, the drive can:
Modify the auxiliary position counter (homing)
Log the exact position of the event (capture)
Flag a digital output (flag)
An event is a change in a digital input signal. The polarity of the change is defined by the
IL[N] command. Values in HY[3] are duplicated for compatibility reasons.
HY[N] (Index)
Value
Description
0
Disarm homing process. HY[1] is automatically reset to 0
when homing is complete.
1
Activation mode
1
Arm homing process. The sequence is activated according
to the last HY[2] to HY 6] values. HY[7] and HY[8] are
cleared.
2
Absolute value
Value to load, according to method of HY[5]. Absolute
value is limited to
position counter range
.
0 Immediate:
Trigger
is
the receipt of HY[1]=1.
1/2
Event according to Auxiliary Home switch (capture).
3
High transition of Index pulse (capture).
4
Low transition of Index pulse (capture).
5/6
Event according to defined FLS switch.
7/8
Event according to defined RLS switch.
9/10
Event according to defined DIN1 switch.
11/12
Event according to defined DIN2 switch.
13/14
Event according to defined DIN3 switch.
15/16
Event according to defined DIN4 switch.
17/18
Event according to defined DIN5 switch.
3
Event definition
19/20
Event according to defined DIN6 switch.
21/22
Event according to defined DIN7switch.
23/24
Event according to defined DIN8 switch.
25/26
Event according to defined DIN9 switch.
27/28
Event according to defined DIN10 switch.
0
In UM=2, 3, 4, 5: stop immediately, using SD deceleration
value. In torque mode (UM=1), do nothing.
1
Set digital output, equivalent to OP=HY[6].
4
After-event
behavior. Defined
as the time in
which HY[1]
decreases to 0.
2 Do
nothing.
