RC - Define Recorded Variables
Purpose:
Defines which signals are to be recorded.
The drive can record a range of signals for performance verification and debugging. The
first step of the recording process is the definition of the recorded variable by assigning a
value to RC, a bit field. Each “on” bit in the binary representation of RC defines a signal
to be recorded. The host can map many optional variables to any bit of RC from bit 0 to
bit 15.
A valid RC defines at least one recorded variable. Up to eight variables can be selected.
Attributes: Type: Parameter, Integer
Source: Program, RS-232, CANopen
Restrictions: Recorder inactive (RR=0 or RR=-1)
Default value: 0 (RS), Non-volatile
Range: See previous description
Unit modes: All
Activation:
Next initiation of recorder (RR)
Notes:
ƒ If the drive has stored a previously-recorded data, setting RC will invalidate this
data. Invalidated data cannot be retrieved.
ƒ The total number of data points that may be recorded is fixed. Therefore, the
number of points per signal depends on the number of signals recorded
simultaneously: the more signals recorded, the fewer points available for each
signal.
See also:
RG , RL , RP[N] , RR , BH
Reference chapter in the SimplIQ Software Manual:
Chapter 7.4, ”The Recorder”
