78
Figure 81 Emap Toolbar
13.2.1 View toolbar
The functions of each button in the toolbar are explained in ‘Appendix B - Toolbars’.
And the full screen mode is the same with ‘10.3.1 View toolbar’.
13.2.2 Position
Please refer the ‘10.3.2 Position’.
13.2.3 Map controls
Map controls are available in the popup menu of a map. Click right mouse button on the background of a
map. You can select menu from the popup menu.
1) Zoom
The background image would be zoomed in and out with these controls.
Table 18 Emap Zoom Controls
Buttons Controls
Zoom in
Zoom out
Fit screen on/off
2) History of the links
You may open a link from the map. These are to move the history of the links in a map.
Table 19 Link Emap Controls
Button Control Button Control
