58
If multiple devices are dragged into a screen in playback view, then the screens would be set with the
devices.
11.1.3 Layout
If a layout is dragged into a screen in the playback view then the screens would be set as the order of the
devices in that layout. And the view would be changed as that layout.
11.2 Playback Controls
There are playback controls in the Timelaps tab.
11.2.1 Calendar and time combo-box
1) Calendar control
The calendar button ( ) is to select the date. The calendar window shows the dates which have the
recorded data or not as red.
Double click a date which has recorded data.
Figure 59 Playback Calendar Control
Table 15 Calendar Controls
Previous Year Next Month
Previous Month Next Year
Today
2) Time combo-box
Click the time combo-box. It shows 24 hours and the red color time means there is recorded data in that
time. Select a time.
