Page 17
Important: Always read and follow the on-screen operating instructions.
• 11
Video Balancer
On-screen
Instructions
Operator Display
Weight
Display
DIM
Icon
*
Mode
Icon
Static Unbalance Icon
(appears when over
1.1 oz is present)
Econo Balance Mode
Icon (If feature is
available and enabled)
* Profile Tire Image
RO Max.
(Instant Reading of
Wheel Runout)
* On selected
screens, can toggle
to a 3D tire image.
Numbered Key
Key Icons
Monitor and Initial Screen Feature Reference
Option Key
Screen Option
Weight
Placement
Arrow
Centering Bar
Weight
Location
Icons
Figure 19 - Monitor and Initial Screen Feature Reference
Static-on-Screen™
