77
PART 6: REPLACEMENT PARTS
NO. 180 STEAM BOOSTER AND STEAM PIPING ASSEMBLY
Fig. 6.16 Part
Item No. No. Part Description Qty.
1 109069 Thermostat w/capillary ............................................................................ 1
--- 107922 Box Thermostat (Not Shown).................................................................. 1
--- 327480 Bracket, Thermostat (Not Shown)........................................................... 1
2 102525 Tee Reducing 3/4" x 1/2 x 3/4" Brass ..................................................... 1
3 100184 Nipple Close /34"NPT Brass ................................................................... 7
4 102399 Bushing Reducing 1-1/4" x 3/4" Brass .................................................... 2
5 104649 Relief Valve 3/4" ..................................................................................... 1
6 107418 Tee Reducing 3/4" x 3/4" x 1/4" Brass ................................................... 1
7 102444 Elbow Street 3/4" x 90° ........................................................................... 3
8 100135 Pressure Gauge 0-60 PSI ......................................................................... 1
9 112437 Needle Valve 1/4 M X F Brass ................................................................ 1
10 102521 Tee 3/4" NPT Brass ................................................................................. 1
11 107316 Union 3/4"C x 3/4"NPT Male ................................................................. 1
12 107500 Elbow Street 1-1/2" x 90° BI ................................................................... 1
13 100978 Bushing Reducing 1-/12" x 3/4" BI ........................................................ 1
14 105803 Nipple Close 3/4"NPT BI ........................................................................ 3
15 105779 Union 3/4"NPT BI ................................................................................... 1
16 109887 Valve 3/4" Steam ..................................................................................... 2
17 108516 Coil, Valve ............................................................................................... A/R
18 109903 Repair Kit Steam-Water .......................................................................... A/R
19 112346 Tee Reducing 1" x 3/4" x 1/2" BI ........................................................... 1
20 105847 Nipple Close 1"NPT BI ........................................................................... 2
21 102402 Bushing Reducing 1/2" x 1/4" NPT BI ................................................... 1
22 100123 Cock Gauge 1/4" ...................................................................................... 1
23 105749 Plug 3/4" NPT BI ..................................................................................... 1
24 101249 Strainer Line 1-1/2" BI ............................................................................ 1
25 105881 Nipple Close 1-1/2" NPT BI .................................................................... 1
26 105774 Tee Reducing 1-1/2" x 1" x 1"NPT BI .................................................... 1
27 107211 Union Elbow 1" x 90 NPT BI .................................................................. 1
28 105705 Bushing Red 1" x 3/4" BI ........................................................................ 1
29 105817 Nipple 3/4" x 4" BI .................................................................................. 1
30 105730 Elbow 3/4"NPT x 90 BI ........................................................................... 1
31 105823 Nipple 3/4" x 5-1/2" BI ............................................................................ 1
32 104828 Valve Ball 3/4" ........................................................................................ 1
33 110768 Strainer Line 3/4" Brass........................................................................... 1
34 325691 Base Booster ............................................................................................ 1
35 112334 U-Bolt 6"ID .............................................................................................. 2
36 112308 Amtrol Steam Booster ............................................................................. 1
37 107550 Valve Pressure Reducing 3/4" ................................................................. 1
38 102442 Elbow 3/4"NPT x 90 Brass ...................................................................... 1
39 102490 Nipple 3/4" x 3-1/2" Brass....................................................................... 1
40 100571 Union 3/4"NPT Brass .............................................................................. 1
41 112349 Bushing Reducing 1-1/2" x 1/2" BI ........................................................ 1
42 100147 Elbow Street 1/2" NPT BI ....................................................................... 1
43 105782 Nipple Close 1/2"NPT BI ........................................................................ 3
44 105778 Union 1/2"NPT BI ................................................................................... 1
45 111380 Steam Trap 1/2"NPT................................................................................ 2
46 105762 Tee Reducing 1" x 1/2" x 1/2"NPT BI .................................................... 1
