75
PART 6: REPLACEMENT PARTS
ELECTRIC BOOSTER AFTER S/N U2769
Fig. 6.15 Part
Item No. No. Part Description Qty.
1 305407 Tank, booster ................................................................................... 1
2 112593 Element, heater 9KW (440/60/3) ................................................... 2
111234 Element, heater 9KW (480/60/3) (Used on USS Nicholas Only) .. 2
3 109985 Gasket .............................................................................................. 2
4 110562 Thermostat, high limit ..................................................................... 1
5 109069 Thermostat, control ......................................................................... 1
6 102442 Elbow, 3/4" x 90° brass ................................................................... 2
7 102683 Nipple 3/4" x 4" brass ..................................................................... 1
8 100571 Union 3/4" brass .............................................................................. 2
9 102653 Nipple, 3/4" x 13-1/2" brass ............................................................ 1
10 102444 Elbow, street 3/4" x 90° brass ......................................................... 3
11 100171 Bushing, reducing 3/4" x 1/2" brass ............................................... 1
12 100184 Nipple, 3/4" close brass ................................................................... 6
13 111437 Valve, 3/4" HW ............................................................................... 1
14 108516 Coil, solenoid .................................................................................. A/R
15 109903 Repair Kit 3/4" ................................................................................ A/R
16 0507463 Tee, 3/4" brass ................................................................................. 1
17 102403 Bushing, reducing 3/4" x 1/4" brass ............................................... 1
18 110768 Line, strainer 3/4" brass .................................................................. 1
19 104828 Valve, ball ........................................................................................ 1
20 107550 Valve, pressure reducing 3/4" .......................................................... 1
21 100135 Gauge, pressure ............................................................................... 1
22
23 0510563 Flange, foot 6" ................................................................................. 4
24 100734 Bolt 1/4-20 x 1/2" Hex Head .......................................................... 4
25 106026 Washer Flat 1/4................................................................................ 4
26 106482 Washer Lock 1/4" Split ................................................................... 4
27 100141 Nut Grip 1/4" ................................................................................... 4
28 102505 Pipe Plug 3/4" NPT Brass ............................................................... 1
29 0710561 Cover, Wrap Weld Assy .................................................................. 1
30
31 0710558 Booster Base, Weld Assy ................................................................ 1
32 0310560 Front Panel, Booster (Not Shown) .................................................. 1
33 0310606 Bracket, Plumbing USN10 .............................................................. 1
