PART 6: REPLACEMENT PARTS
DOORS, GAUGES, SWITCHES
Fig. 6.1 Part
. y t Q n o it p i r c s e D t r a P . o N . o N m e t I
1 0710227 Door ............................................................................................... 1
2 200087 Indicator, water level ..................................................................... 1
3 0709714 Access, door lower ........................................................................ 1
7 107440 Thermometer 8 ft. lead .................................................................. 1
8 113622 Thermometer 4 ft.gas filled .......................................................... 1
9 111026 Magnet, door safety switch ........................................................... 1
10 111090 Switch, magnetic reed (Not shown) .............................................. 1
11 104985 Nut (10-32) .................................................................................... 2
12 0501412 Screw (10-32 x 3/8" Truss hd) ...................................................... 2
13 0309301-1 Bracket, switch .............................................................................. 1
14 0310234 Hinge, Door Support ..................................................................... 2
15 110233 Catch, door (Prior to S/N U10023393).......................................... 1
16 107893 Shock Absorber ............................................................................. 2
17 110228 Pin, Door ....................................................................................... 2
18 0309228 Reed Switch Bracket Not Shown) ................................................ 1
19 100003 Nut, Plain 1/4-20 SST................................................................... 5
20 0509251 Thumbscrew 1/4-20 x 2 3/4" SST ................................................ 1
21 0501425 Screw 8-32 x 5/8 Round Head SST.............................................. 4
22 0501497 Washer, Split Lock #8 ................................................................... 2
23 107965 Nut, Grip 8-32 w/Nylon Insert ..................................................... 2
24 0501419 Bolt, 1/4-20 x 1/2" Hex Head SST ............................................... 4
25 0501501 Lock Washer 1/4 ........................................................................... 4
26 114747 Catch, Door (Beginning with S/N U10023393)............................. 1
27 107965 Grip nut, 8-32 w/nylon insert......................................................... 4
28 100752 Screw, 8-32 x 1/2" Flat Hd. SST.................................................... 4
29 333565 Bracket, Terminal (Beginning with S/N U10023393)................... 1
30 100294 Block, Terminal 6PT (Beginning with S/N U10023393).............. 1
-- 0709713 Door Assembly (includes 3, 4, 5, 6) ............................................. A/R
4 900856 Switch, Selector (Power)............................................................... 1
5 900857 Switch, Selector (Wash, Rinse)..................................................... 1
6 900858 Switch, Pushbutton Lighted Green............................................... 1
