PART 6: REPLACEMENT PARTS
CONTROL CABINET (AFTER S/N G3600)
Fig. 6.10 Part
Item No. No. Part Description Qty.
1 110920 Connector, Sealtite 1" x 90 ............................................................. 2
2 0509706 Circuit Board (Includes item 19)..................................................... 1
3 109604 Transformer (208-240/480V:115VAC) ........................................... 1
4 104873 Label Ground................................................................................... 1
5 111904 Terminal Block ................................................................................ 1
6 103309 Wire Lug, Ground ........................................................................... 1
7 111827 Contactor 60 FLA 3P 120 Coil (Tank Heat).................................... 1
8 100906 Fuse ATMR-5 600V One Time ....................................................... 3
9 112901 Fuse ATDR-1 Time Delay ............................................................... 2
10 106402 Block Fuse (2Pole) .......................................................................... 1
11 106925 Block Fuse (30A, 3 Pole) ................................................................ 1
12 111827 Contactor 60FLA 3P 120 Coil (Booster Heat) ................................ 1
13 111626 Starter, Mtr 1.6-2.4 AMP................................................................. 1
14 108130 Contact Auxiliary TM#LA1-DN11................................................. 1
15 108122 Contactor 12A LC1D1210G6.......................................................... 1
16 111068 Relay 120V...................................................................................... 4
17 111036 Socket Relay.................................................................................... 4
18 313114 Control Cabinet Weldment .............................................................. 1
19 113123 Fuse 1Amp 250V 5 x 20mm ........................................................... 1
