19
PART 3: OPERATION
19. Check the direction of rotation of the pump motor.
Proper rotation is CW when viewing the motor from the rear.
WARNING:
Dangerous voltages are present at the local electrical distribution system.
Dangerous voltages are present at the dishwasher when it is connected to the
local electrical distribution system.
WARNING:
When working on the dishwasher, disconnect the electric service and place a tag at the
disconnect switch to indicate work is being done on that circuit.
20. If rotation direction is incorrect, reverse wires L1 and L2 on the disconnect switch side of
the main electrical connection terminal block located inside the remote control cabinet.
21. Proceed to Part 3.4, Safety and Operation Checks, on next page
