PART 6: REPLACEMENT PARTS
CONTROL CABINET (PRIOR TO S/N G3599)
Fig. 6.9 Part
Item No. No. Part Description Qty.
1 109064 Transformer (208-240/480V: 115VAC)........................................... 1
2 111068 Relay 2PDT 10A 120VAC Coil...................................................... 2
3 111626 Overload, motor 1/2 HP Wash (480V/60/3) ................................... 1
4 108122 Contactor, 1/2 HP Wash motor (12A 3 pole) ................................... 1
5 111904 Contactor, booster heater (40A, 3 pole) .......................................... 1
6 106925 Block, fuse (30A, 3 pole) ................................................................ 1
7 100906 Fuse, 5A 480V/3.............................................................................. 3
8 106402 Block, fuse (2 pole) ......................................................................... 1
9 0508707 Fuse, 1A 480V/3.............................................................................. 2
10 109069 Thermostat, control ......................................................................... 1
11 0509706 Circuit Board ................................................................................... 1
12 108311 Breaker, circuit (3A)........................................................................ 1
13 0309745 Box, control ..................................................................................... 1
14 111036 Socket Relay.................................................................................... 2
15 0508708 Fuse 2.5Amp 600V (Not Shown) .................................................... 2
— 103309 Wire lug, ground (Not shown) ........................................................ 1
— 0509705 Harness, wiring................................................................................ 1
