12
2.9 Chemical Connections
Perform the following steps to connect the chemical dispensing equipment (supplied by others).
WARNING:
The installation of electrical supplies and controls must conform to local codes or, in the
absence of local codes, the National Electrical Code and good trade practices.
WARNING:
Dangerous voltages are present at the local electrical distribution system.
Dangerous voltages are present at the dishwasher when it is connected to the
local electrical distribution system.
WARNING:
When working on the dishwasher, disconnect the electric service and place a tag at the
disconnect switch to indicate work is being done on that circuit.
1. Chemical dispensing signal connection points are provided in the control cabinet.
2. The detergent signal is limited to a maximum load of 1 Amp. Signal voltage is 120VAC.
3. The Rinse aid signal is limited to a maximum load of 1 Amp. Signal voltage is 120VAC.
4. Sanitizer is not required for the USN-10 dishwasher.
5. The rinse aid injection point is located in the upper final rinse piping of the dishwasher.
6. The chemical equipment installer must cut a hole in the wash tank for a detergent
sensor and a detergent injection point.
PART 2: INSTALLATION
