11
PART 2: INSTALLATION
2.8 Electrical Connections
Perform the following steps to connect the electrical supply.
WARNING:
The installation of electrical supplies and controls must conform to local codes or, in the
absence of local codes, the National Electrical Code and good trade practices.
WARNING:
Dangerous voltages are present at the local electrical distribution system.
Dangerous voltages are present at the dishwasher when it is connected to the
local electrical distribution system.
WARNING:
When working on the dishwasher, disconnect the electric service and place a tag at the
disconnect switch to indicate work is being done on that circuit.
1. A qualified electrician must compare the electrical power supply with the machine electrical
specifications stamped on the MACHINE ELECTRICAL CONNECTION PLATE located
inside the control cabinet before connecting to the incoming service through a fused disconnect
switch.
2. Locate the dishwasher main electrical junction box for the machine.
The box is located either to the left or right of the dishwasher (depending on how the machine
was originally ordered from the factory).
3. Controls must be easily accessible to the operator.
4. Install the power supply wires from the local distribution panel to the control cabinet
at the incoming power terminal block.
5. Refer to Part 3.3, Start up procedure to test the installation.
