17
PART 3:
OPERATION
Table 3.2
Controls and Indicators
Dishwasher
Inlet water
Ball valve
Connects incoming water supply
valve
for the booster
Inlet water
Ball valve
Connects incoming water supply for
supply valve
the tank fills.
Inlet water
Ball valve
Controls manual fill to wash tank
supply valves
Water level
Sight glass
Indicates water level in wash
gauges
Water line visible in
center of glass indicates correct
water level in tank.
Tank water
Scaled
Indicates water temperature in
temperature
thermometer
wash and rinse.
gauges
dial
Wash = 150°F minimum
Rinse = 180°F minimum
Final rinse
0-60 PSI
Indicates final rinse water pressure
gauge
during the final rinse.
20-22 PSIG minimum flow pressure
Final rinse
Scaled
Indicates final rinse temperature
gauge
thermometer
during the final rinse
dial
180-195°F optimum range
CONTROL
TYPE
FUNCTION
1
2
3
4
5
6
7
