2.2 Permanent Placement

Perform the following steps to place the dishwasher in its permanent location.

1. Before moving the sections into position, inspect the location site to ensure the electrical,

plumbing, and ventilation services are provided in the correct locations. Compare the site

connections with the dishwasher to ensure they will match when the machine is set in its

permanent location.

CAUTION:

Check piping mounted underneath dishwasher before lifting to avoid damaging the machine.

2. Lift the dishwasher and replace the adjustable legs with flanged mounting feet provided.
3. Position dishwasher in its permanent location.
4. Level the dishwasher front to back and side to side by turning the adjustable feet.

Make sure the load and unload openings align with the table system height.

5. Position the external booster heater at the unload end of the dishwasher.

Check alignment of common plumbing connections between booster and dishwasher.

6. Mount control cabinet to location nearest machine (if applicable).
7. Install deck plates and bolt dishwasher and booster to deck per standard procedures.

2.3 Connections between the dishwasher and booster

(Steam Only)

WARNING:

The installation of this unit must conform to local codes or, in the absence of local codes,
to the National Electrical Code and all National Codes governing plumbing, sanitation,
safety and good trade practices.

Connect the plumbing and electrical connections between the dishwasher and booster heater.

1. Connect the 1/2" condensate union from the dishwasher to the booster.
2. Connect the 3/4" steam union from the dishwasher to the booster. .
3. Connect the 3/4" water line from the booster to the top of the dishwasher at the

vacuum breaker.

4. Pull the electrical conduit and harness from the junction box located on the lower

rear corner of the dishwasher to the booster junction box located on the lower left rear leg

of the booster stand.

5. Match the harness wire numbers to the booster junction box wiring.
