PART 6: REPLACEMENT PARTS
WASH AND RINSE SPRAY
SYSTEM
Fig. 6.2 Part
Item No. No. Part Description Qty.
1 180282 Nozzle, Rinse Rigid ......................................................................... 4
2 0510090 Manifold, Wash Piping..................................................................... 1
3 0710087 Wash Arm ......................................................................................... 2
4 0510088 Bearing, Wash Arm .......................................................................... 2
5 109837 Retainer, Upper Wash Arm .............................................................. 1
6 0507443 Spindle, Lower Rinse Arm............................................................... 1
7 113514 Bearing, Rinse Arm ......................................................................... 2
8 0710247 Rinse Arm ........................................................................................ 1
9 113220 Breaker, Vacuum 1/2" ...................................................................... 1
10 108349 Kit, Vacuum Repair 1/2" (not shown) ............................................. 1
11 0710565 Manifold, Rinse Piping Assy ........................................................... 1
12 0507444 Nut, Rinse arm ................................................................................. 1
13 104005 Nozzle, Rinse Arm Rotating ............................................................ 4
14 0510269 Spindle, Upper Wash........................................................................ 1
15 0510268 Spindle, Lower Wash ....................................................................... 1
— 0710089 Rinse Arm Assy (includes 7,8, and 16) ........................................... —
— 0710086 Wash Arm Assy complete (Includes items 4-5) ............................... —
